The Waveshare 31618 is the 7-DSI-LCD-H-WITH-CASE product which is a 7-inch Capacitive Touch Display, 1280×720 Pixels, IPS Panel, Optical Bonding Toughened Glass Panel, 10-Point Touch, Anti-Fingerprint Process, With Protective Case.
Part No: 7inch DSI LCD (H) (with case) is product provided.
(suitable for Raspberry Pi 5 only)
7″ DSI Capacitive Touch Display
Device & System Support
Connection examples
Working with Raspberry Pi 5
Please connect the FPC cable as shown below, and power the LCD through the GPIO 5V pin
With protective case (suitable for Raspberry Pi 5 only)
Working with Raspberry Pi 4B
Working with ESP32-P4-NANO
Working with Luckfox Lyra
Working with Luckfox Omni3576
* for reference only, the above controller boards or hosts are NOT included.
IPS Display PanelExcellent Display Performance With 170° Wide Viewing Angle
Supports backlight adjustment via software
Thinner and more space-saving
Integrates the driver circuit into an FPC cable, the total thickness of the LCD is only 9.3mm
Interface definition
With protective case
How to install
First, fix the silicone button cap inside the case as picture below,
and then use the PM2.5 * 4mm black metal screws to secure the case and screen
Standard version
The protective case
Wiki: 7-DSI-TOUCH-A
